SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 17 / 63
5.10 AMI Command
AMI Command is used to get the controller own-information.
▣ Request Message Frame
bytes 1 2 3 2 1 1
Frame STX Address AMI SUM CR LF
▣ Response Message Frame
bytes 1 2 3 1 2 1
Frame STX Address AMI , OK ,
9 2 7 2 1 1
Model Name SPACE Version-Revision SUM CR LF
◈ Example
To confirm controller own information
- Request : [STX]01AMI[CR][LF]
- Request (with CheckSum) : [STX]01AMI38[CR][LF]
- Response : [STX]01AMI,OK,TEMP-2000[sp][sp]V00-R00[CR][LF]
- Response (with CheckSum) : [stx]01AMI,OK,TEMP-2000[sp][sp]V00-R0024[cr][lf]
To Next Page
