Samwontech TEMP2500 Communications Manual

SAMWONTECH
1th Edition of TEMP2000_Series IM : Dec. 15. 2008 Page 20 / 63
6.3 Function code - 03
Function code-03 is used to read the data of consecutive D-Register block in sequence up to 64 registers.
▣ Request Message Frame
Factor ASCII RTU
Protocol Header :(Colon) -
Slave Address 2 characters 8-Bit
Function code-03
2 characters
8-Bit
D-Register Hi
2 characters
8-Bit
D-Register Lo
2 characters
8-Bit
Address Count Hi
2 characters
8-Bit
Address Count Lo
2 characters
8-Bit
Error detecting
2 characters
16-Bit
Protocol Tail 2 characters (CR+LF) -
◈ Exmaple
Request message to read the D-Register FROM D0001 (NPV) TO D0003 (NSP) should be
- MODBUS ASCII :010300000003F9[cr][lf]
- MODBUS RTU 01030000000305CB
☞ D-Register has to be subtracted ‘1’ from the designated address number on D-Register table in this manual.
▣ Response Message Frame
Factor ASCII RTU
Protocol Header :(Colon) -
Slave Address 2 characters 8-Bit
Function code-03
2 characters
8-Bit
Data byte count
2 characters
8-Bit
Data - 1 Hi
2 characters
8-Bit
Data - 1 Lo
2 characters
8-Bit
… … …
Data - n Hi
2 characters
8-Bit
Data - n Lo
2 characters
8-Bit
Error detecting
2 characters
16-Bit
Protocol Tail 2 characters (CR+LF) -
◈ Exmaple
Response data will be same as below, when 49.3 of D0001 (NPV) and 10.8 of D0003 (NSP)
- MODBUS ASCII :01030601ED0000006C9C[cr][lf]
- MODBUS RTU 01030601ED0000006C8C9E
