Look Inside for:
Page
Safety Definitions 1
Important Safety Information 2-4
Specifications 5
Features 5
Assembly 6
Engine Preparation 7-8
Operation 9-12
Maintenance 13-18
Technical Service 18
Troubleshooting 19
Warranty 20-23
Español 24
03/11/2008 Printed in China A101104
Operator’s Manual
FIELD TRIMMER
160 cc, 4 Cycle
IMPORTANT:
Thank you for purchasing this Sanborn™ Trimmer.
This manual provides complete instructions for safely operating and maintaining your Trimmer. Read and save these
instructions. Refer to this manual each time before using your Trimmer.
Record the following for future reference:
Mfg. Date Code: ______________________
Date of Purchase: Attach a copy of your sales receipt.
Consumer Toll Free Number: 1-800-737-2112
KEEP THIS MANUAL FOR FUTURE REFERENCE
MODEL Nos. SB-WFT-16022-[E]
SB-WFT-16022
If you have a question or problem...
CALL TOLL FREE: 1-800-737-2112
This product contains one or more chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
WARNING
TM

Table of Contents

Questions and Answers

  • R
    Ryan MontgomeryAug 15, 2025
    Why does my Sanborn Trimmer engine smoke or run rough?
    • M
      Melissa MooreAug 15, 2025
      If your Sanborn Trimmer experiences engine problems such as excessive smoke, rough running, erratic behavior, or inability to maintain full speed, consider these potential causes: 1. There may be no engine oil; add engine oil. 2. The engine oil level might be incorrect; check and adjust as necessary. 3. The spark plug could be fouled; inspect and replace if needed. 4. The air filter might be clogged; remove and clean it. 5. The fuel filter might be clogged; inspect and replace if needed. 6. The carburetor might be out of adjustment; take the unit to an authorized service center for adjustment. 7. The fuel might be contaminated; drain the tank, clean it, and refill with fresh fuel.
  • D
    Dakota MitchellAug 20, 2025
    Why is my Sanborn Trimmer trimming poorly?
    • A
      andreawheelerAug 20, 2025
      If your Sanborn Trimmer is not trimming well, it might be due to the trimmer line being too short. Replace it with the correct length trimmer line (22 inches). Another reason may be that the engine is not at full throttle; move the throttle lever to the FAST position. Also, engine problems can cause poor trimming performance, so refer to engine solutions.
  • T
    Tracy BradyAug 26, 2025
    How to fix excessive vibration or noise in my Sanborn Trimmer?
    • J
      Justin CannonAug 26, 2025
      Excessive vibration or noise in your Sanborn Trimmer can be caused by a few things. First, check for loose parts and tighten all fasteners. Second, ensure that the trimmer lines are of equal length; replace them if they are not. Third, see if the set screws in the trimmer head are loose; tighten them with a T-handle wrench. Finally, engine problems can cause excessive vibration or noise, so refer to engine solutions.
  • G
    gonzalesbrittanyAug 30, 2025
    What to do if the Sanborn SB-WFT-16022 head does not retain line?
    • I
      iwilliamsAug 30, 2025
      If the trimmer head on your Sanborn Trimmer does not retain the line, it might be because the trimmer line is not properly attached. Follow the instructions in the maintenance section for attaching the line. It could also be due to a broken line retainer, in which case you should have the trimmer head assembly replaced. Make sure you are using the correct size trimmer line (0.155 in. / 4 mm). Finally, if the trimmer line is too brittle, use a trimmer line that has been soaking in water.
  • C
    colemannicholasSep 4, 2025
    What to do if my Sanborn SB-WFT-16022 Trimmer engine will not stop?
    • N
      Nicholas CraigSep 4, 2025
      If the engine of your Sanborn Trimmer will not stop, inspect the throttle control lever and wire. Replace them if necessary.
  • R
    Robert BautistaNov 9, 2025
    Why is my Sanborn SB-WFT-16022 Trimmer engine difficult to start?
    • G
      Gregory DoughertyNov 9, 2025
      If the Sanborn Trimmer engine is difficult to start, there are several potential causes: * It might be out of fuel, in which case you should add fresh fuel. * The throttle might be in the Stop position; move it to the Start position. * The engine might not be primed; press the Primer bulb 3 times, waiting 2 seconds between each push. * The engine could be flooded; wait a few minutes before attempting to start it again. * The spark plug wire might be disconnected; attach it to the spark plug. * The throttle control lever or wire might be defective; inspect and replace if necessary. * The spark plug could be fouled; remove, inspect, and replace if needed. * The air filter might be clogged; remove and clean it. * The fuel filter might be clogged; remove, inspect, and replac...
