V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230336
CABINET ASSEMBLY (HVV)
ITEM NO.
DESCRIPTION
QTY REQ
PART NO.
1*
CABINET ASSEMBLY - FOAMED
1
~
2
HINGE PIN
1
389071
3
RAMP
1
1120387
4
LEVELING LEG
4
1059902
5
CONDENSATE PAN
1
1122475
6 DRAIN TUBE 1 1088449-1
7
NUT - DRAIN TUBE
1
387925
8
DRAIN TUBE GASKET
1
387837
9
DRAIN TUBE FUNNEL
1
1068678
10
FIBERGLASS EVAPORATION BOARD
1
1122728
11
BRACKET - REFRIGERATION
2
1123527
12
LATCH RECEPTACLE ASSEMBLY
1
1121186
13**
SIDE DECAL
2
**
14
STACK SUPPORT (OBS)
1
~
15
TOP HINGE
1
2000805-03
16 BRACKET STACK SUPPORT 2 1148205
17
AIR DAM/KICK PANEL ASSEMBLY, 39”
1
1126880
AIR DAM/KICK PANEL ASSEMBLY, 32”
1
1126880-1
18
DOOR SWITCH BRACKET
1
1126691
19
DOOR SWITCH
1
323007
20
OVERLAPPING DOOR GUARD - 72”
1
2001376
OVERLAPPING DOOR GUARD - 79”
1
2002325
21
SEAL, 39”
1
1122500
SEAL, 32”
1
1122500-1
22
VEND CHUTE, 39”
1
1121926-8
VEND CHUTE, 32”
1
1123451
23
CHUTE BRACKET
1
1148228
24
DROP SENSOR
1
1122923
25
SAFETY SCREEN, 39”
1
1225776
SAFETY SCREEN, 32”
1
1239473
26
DROP SENSOR MOUNTING BRACKET
1
1123601
27
FOAM PAD, DROP SENSOR
2
1123654
28***
QUICKER LOCK ASSEMBLY
1
1126566
29
LATCH BRACKET
1
1126428
30
NUT RETAINER
1
1123689
31
NUT SEGMENT
3
1033085
32
LOCK SPRING
1
389690
33
CAP
1
1111988
34
WASHER
1
389026
35
#8 X 1-1/4” PAN HEAD SCREW
2
V802139
36
1/4” X 1” HEX HEAD SCREW
4
V801490
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-20 & C-21.
*WHEN ORDERING CABINET ASSEMBLY, PLEASE PROVIDE 9-CODE OR 11-CODE AND MANUFACTURER’S DATE CODE.
**WHEN ORDERING DECALS, PLEASE PROVIDE STYLE. ***QUICKER LOCK OPTION ONLY AVAILABLE IN 621 MODEL.
V21 Cabinet Parts | C-10
