V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230336
MECH PLATE ASSEMBLY
ITEM
NO.
MODEL NUMBER
521
621
721/821
DESCRIPTION
QTY
REQ
PART
NO.
QTY
REQ
PART
NO.
QTY
REQ
PART
NO.
1
VEND MOTOR ASSEMBLY
7
1122820
8
1122820
10
1122820
2
FRONT SPACER
7
1122814
8
1122814
10
1122814
3
VEND BUCKET
7
1181622
8
1122815
10
1122815
4
CAN CLIP
~
~
8
1122856
10
1122856
5
GATE
7
1183242
8
1122818
10
1122818
6
E-CLIP – GATE
7
1122818
8
V801080
10
V801080
7
GATE LINK
7
1122819
8
1122819
10
1122819
8
SPRING
7
390326
8
390326
10
390326
9
COUPLING CAM
7
1122817
8
1122817
10
1122817
10
REAR BUSHING
7
385603-6
8
1122816
10
1122816
11
FRONT BUSHING
7
1122816
~
~
~
~
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-20 & C-21.
*DEPENDING ON PRODUCT
V21
Cabinet Parts | C-14
