V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230344
CHAMELEON 3D VISION DOOR
* NOTE: WHEN ORDERING DOOR ASSEMBLY, PLEASE PROVIDE 9-CODE OR 11-CODE AND
MANUFACTIRERS DATE CODE.
** NOTE: PART NUMBER AND/OR QUANTITY IS CONFIGURATION DEPENDENT. CONTACT
CUSTOMER SERVICE FOR ASSISTANCE.
ITEM NO.
MODEL NUMBER
821 VIS
HARDWARE
DESCRIPTION
QTY
REQ
PART NO.
1
DOOR WELD
1
1187325-1
2
SIGN FACE
1
1221169
3
BEZEL, CONSUMER INTERFACE
1
1143346
D
4
BEZEL, COIN RETURN
1
1170855-1
D
5
RAIN GUARD
1
2000848
K
6
PNT, MTG, BRKT, TOP/BTM, VIS, 821
2
1224518
R, Y
7
PNT, MTG, BRKT, SIDE, VIS, 821
2
1224509
R, Y
8
SUPPORT BRACKET
1
1143486
9
LENS, DISPLAY-BLUE
1
1121103
10
COVER, DBV (OPTIONAL)
1
1144557
S
11
COIN RETURN BUTTON
1
1050473
12
DOOR GUARD
1
2010131
R, Y
13
DOOR ROLLER
1
1120388
A, J
14
DOOR ROLLER BRACKET
1
1239376
A, K
15
BUSHING HINGE
2
388094
16
BRKT, SELECTION BUTTON SUPT.
1
1220009
17
SELECTION SWITCH
8
368299
18
HOLDER, SELECTION SWITCH, HAPP
8
1149385
19
PLASTIC NUT
8
1073538
20
PLASTIC WASHER
8
1073511
21
BUTTON ASY, ROUND, CHAMELEON
8
1149374
V21 Door Parts Chameleon | D1-5
