SandenVendo V21 621 - Page 129

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230344
CHAMELEON TRADE / 3D VISION DOOR (CONTINUED)
ITEM
NO.
MODEL NUMBER
721
821
HARDWARE
DESCRIPTION
QTY
REQ
PART NO.
QTY
REQ
PART
NO.
1
HINGE – INNER DOOR, MALE
2
1121287
2
1121287
F
2
MOUNTING BRACKET - CONTROLLER
1
1124704
1
1124704
H
3
STAND OFF
7
1121740
7
1121740
4
PCBA VEC 12.1 CONTROLLER
1
1167867
1
1167867
5
PCBA COVER PANEL
1
1123049
1
1123049
H
6
PLATE, DBV PLUG, UPPER
1
1143498
1
1143498
F
7
COIN INSERT CHUTE
1
1121066
1
1121066
U
8
ASY,COIN RETURN LEVER
1
1182651
1
1182651
F
9
DOOR BUMPER
2
1036912
2
1036912
10
DELIVERY HOPPER ASSEMBLY
**
1149325
1
1149325
D, K
10
DELIVERY HOPPER ASSEMBLY VIS
**
NA
1
1222353
R, Y
11
LAMP – 17W T-8, 24”
3
1130637
3
1130637
LAMP LED 24”
2
1237136
2
1237136
12
LAMP – 32W T-8, 48”
2
1121173-2
2
1121173-2
LAMP LED 48”
2
1237136-1
2
1237136-1
13
BKT, LIGHT, UPPER
2
1150387
~
~
14
BULB, HOLDER, PLUNGER
4
1151265
4
1151265
15
RAIN GUTTER
1
1121204
1
1121204
K
16
PNL, SHR, LWR, 39” 4-BLB
PNL, SHR, UPR, 39”, 4-BLB
1
1
1238949
1238868
1
1238949
1238868
K
17
LAMP BRACKET LOWER PROFILE
6
1151367
8
1151367
F
18
PNL, SHR, MIDDLE
1
1122308
1
1122308
19
LAMP EXTENSION BRACKET
2
1150259
~
~
20
BRKT, LAMP, HO, EXT
2
~
2
~
21
COIN CHUTE COVER
1
1181555
1
1181555
22
BALLAST COVER
1
1190155
1
1190155
23
BALLAST
1
1127052
1
1127052
V21
Door Parts Chameleon | D1-7
