SandenVendo V21 621 - Page 135

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230352
CHAMELEON ADA TRADE DOOR
ITEM
NO.
MODEL NUMBER 521
621
721
821
HARDWARE
DESCRIPTION
QTY
REQ
PART NO.
QTY
REQ
PART NO.
QTY
REQ
PART NO.
QTY
REQ
PART NO.
1
DOOR WELD
1
1182341
1
1190026
1
1189097
1
1189232
2
SIGN FACE
1
**
1
**
1
**
1
**
3
SIGN CAP, TOP
2
389305
1
1127305
1
1114341
1
1114341
K
4
SIGN CAP, BOTTOM
~
~
1
1127510
1
1114341-1
1
1114341-1
5
SIGN TRIM, VTL, RIGHT,
72”
1 1182479 1 1149889 1 1149889 1 1150455 K
6
SIGN TRIM, VTL, LEFT,
72”
1 1182481 1 1149891 1 1149891 1 1150466 K
7
BEZEL, CONSUMER
INTERFACE
1 1143346 1 1143346 1 1143346 1 1143346 D
8
TRIM EYELET, CURVE
1
388271
1
388271
1
388271
1
388271
D
9
BUTTON ASY, ROUND,
CHAMELEON
6 1149374 6 1149374 ** 1149374 ** 1149374
10
PLASTIC NUT
6
1073538
6
1073538
**
1073538
**
1073538
11
SELECTION SWITCH
6
368299
6
368299
**
368299
**
368299
12
BRACKET, SIGN FACE
3
1182388
2
1163504
**
**
**
**
H
13
SUPPORT BRACKET
1
1143486
1
1143486
1
1143486
1
1143486
14
DOOR ROLLER BRACKET
1
1239376
1
1239376
1
1239376
1
1239376
V802196
15
DOOR ROLLER
1
1120388
1
1120388
11
1120388
1
1120388
V802162
16
BUSHING HINGE
2
388094
2
388094
2
388094
2
388094
17
RAIN GUARD
1
1182455
1
2005937-2
1
2000848
1
2000848
18
DOOR GUARD
1
1183151
1
2010131
1
2010131
1
2009503
AE
19
COIN SUPPORT PLATE
1
1143475
1
1143475
1
1143475
1
1143475
H
20
COIN RETURN BUTTON
1
1050473
1
1050473
1
1050473
1
1050473
21
COVER, DBV
(OPTIONAL)
1 1144557 1 1144557 1 1144557 1 1144557
22
LENS, DISPLAY-BLUE
1
1121103
1
1121103
1
1121103
1
1121103
S
23
COIN RETURN BEZEL
1
1170855-1
1
1170855-1
1
1170855-1
1
1170855-1
D
24
COIN RETURN CUP
1
1143414
1
1143414
1
1143414
1
1143414
H
25
DISPLAY BOARD, 2X20
1
1137414
1
1137414
1
1137414
1
1137414
* NOTE: WHEN ORDERING DOOR ASSEMBLY, PLEASE PROVIDE 9-CODE OR 11-CODE AND
MANUFACTIRERS DATE CODE.
** NOTE: PART NUMBER AND/OR QUANTITY IS CONFIGURATION DEPENDENT. CONTACT
CUSTOMER SERVICE FOR ASSISTANCE.
V21
Door Parts Chameleon ADA | D2-3
