SandenVendo V21 621 - Page 171

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230395
V21 TRADE OUTER DOOR - 4 BULB LIGHTING
ITEM
NO.
MODEL NUMBER
621
721
821
DESCRIPTION
QTY
REQ
PART NO. PART NO. PART NO.
1
DOOR WELD - BLACK
1
1197768
1197241
1197393
2
HINGE - INNER DOOR, MALE
2
1121287
1121287
1121287
3
MOUNTING BRACKET - CONTROLLER
1
1124704
1124704
1124704
4
STAND OFF
7
1121740
1121740
1121740
5
PCBA VEC 12.1 CONTROLLER
1
1123051-12.1
1123051-12.1
1123051-12.1
6
COVER PANEL
1
1123049
1123049
1123049
7
COIN DOOR ASSEMBLY
1
1081155
1081155
1081155
8
LATCH - COINAGE DOOR
1
1085546
1085546
1085546
9
BARRIER PANEL
1
1148198
1148198
1148198
10
BULKHEAD COIN BOX SUPPORT
1
1197689
1197689
1200135
11
SHEAR PANEL - MIDDLE (FLAT DOOR) - (NP)
1
1120713
1120713
~
SHEAR PANEL - MIDDLE, 4-BULB T-8
1
~
1122308
1122308
12
DOOR BUMPER
2
1036912
1036912
1036912
13
RAMP/CATCH - INNER DOOR
1
1121714
1121714
1121714
14
COIN BOX ASSEMBLY
1
1088058
1088058
1088058
15
BALLAST, 3-4 LAMP, 120/277V, 50/60HZ
1
1127052
1127052
1127582
16
SHEAR PANEL – LOWER
SHEAR PANEL – UPPER
1
1
~
1123915
1241672
1238949
1238868
17
HARNESS TIE
3
1088864
1088864
1088864
18
LAMP HOLDER - FIXED, MEDIUM BI-PIN
4
1151253
1151253
1151253
19
RAIN GUTTER
1
1121204
1121204
1121204
20
LAMP HOLDER - PLUNGER, MEDIUM BI-PIN
4
1151265
1151265
1151265
21
BRACKET - LAMPHOLDER
8
1122305
1122305
1122305
22
LAMP - 17W T-8, 24”
2
~
1130637
1130637
LMAP, LED, 24”
2
~
1237136
1237136
23
LAMP - 32W T-8, 48”
2
~
1121173-2
1121173-2
LAMP, LED, 48”
2
~
1237136-1
1237136-1
24
DOOR HARNESS
1
1122905
1122905
1122905
25*
RAIN COVER BRACKET, BALLAST
1
1121838-1
1121838-1
1121838-1
26
RAIN CURTAIN, LIGHTS - (NP)
2
1121838
1121838
1121838
27
MDB HARNESS - (NP)
1
1124570
1124570
1124570
28
LABEL, CAUTION, T-8 LAMPS ONLY
1
1122973
1122973
1122973
29*
GROMMET
1
388090
388090
388090
30
BALLAST, 230V, 50HZ - (NP)
1
1121313
1121313
1121313
31
SHEAR PANEL, LWR (621 FLAT DOOR) - (NP)
1
1123925
~
~
32
SHEAR PANEL, UPR (621 FLAT DOOR) - (NP)
1
1123669
~
~
NOTE: FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
NOTE: (NP) – NOT PICTURED
*EARLY PRODUCTION AND INTERNATIONAL UNITS (PRE-2011)
V21
Door Parts Trade ADA | D5-7
