V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230395
V21 TRADE SELECTION PANEL
ITEM
NO.
MODEL NUMBER
621
721/821
DESCRIPTION
QTY
REQ
PART NO.
QTY
REQ
PART NO.
1
SELECTION PANEL ASSEMBLY-TRADE
CURVE/FLAT (10/8 SELECT)
1 2007325-013 1 2007325-011
2
SELLECTION WINDOW & BUTTON
ASSEMBLY
8 1036203-4 10 1036203-4
3
SELECTION WINDOW ASSEMBLY
8
133431
10
133431
4
SELECTION WINDOW
8
388223
10
388223
5
SELECTION WINDOW - BACK
8
388116
10
388116
6
SELECTION BUTTON
8
1116775
10
1116775
7
SELECTION SPRING
8
388858
10
388858
8
BUTTON HOUSING
8
1006932
10
1006932
9
SELECTION SWITCH
8
368299
10
368299
10
SOLD-OUT PLUG
8
1006975-1
10
1006975-1
11
SELECTION PANEL
1
2010183
1
2010158
12
SELECTION HARNESS
1
1117872
1
1111287
13
DISPLAY HARNESS
1
1126164
1
1126164
14
COIN RETURN BUTTON
1
1050473
1
1050473
15
COIN INSERT/RETURN GUIDE PLATE
1
2001481
1
2001481
16
DISPLAY LENS
1
1141039
1
1141039
17
DIGITAL DISPLAY PCB - ELECTRONIC
1
1132544
1
1132544
18
COIN CHUTE ASSEMBLY
1
1087961
1
1087961
19
COIN CHUTE
1
1002333
1
1002333
20
CHUTE COVER
1
1002341
1
1002341
21*
COIN INSERT PLATE
1
--
1
--
22
COIN INSERT SECURITY PLATE
1
2001481
1
2001481
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
* NOTE: WHEN ORDERING COIN INSERT PLATE, PLEASE SPECIFY STYLE.
V21
Door Parts Trade ADA | D5-13
