SandenVendo V21 621 - Page 179

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230395
V21 ADA TRADE INNER DOOR
ITEM
NO.
MODEL NUMBER
621
721
821
DESCRIPTION
QTY
REQ
PART NO. PART NO. PART NO.
1
INNER DOOR ASSEMBLY
1
134302-166
134302-163
134302-164
2
RAIN SEAL, INNER DOOR, 7"
1
1111732-2
1111732-2
1111732-2
3
INNER DOOR SEAL
1
1075678-2
1075678
1075678-1
4
UPPER PRODUCT RETAINER
ASSEMBLY
1 1185792 1185792-1 1185792-2
5
UPPER PRODUCT RETAINER
1
1185778
1181827
1181827-1
6
LONG CLIP RETAINER
1
1125202
1125202
1125202-1
7
INNER DOOR HINGE, FEMALE
2
1121286
1121286
1121286
8
HINGE PIN
1
389192
389192
389192
9
REVERSABLE VEND FLAP
1
1013076
1013076
1013076
10
INNER DOOR EYELET
1
387273
387273
387273
11
GROMMET
1
388090
388090
388090
12
INNER DOOR LATCH
1
1121711
1121711
1121711
13
INNER DOOR LATCH BRACKET
1
1121712
1121712
1121712
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
V21 ADA TRADE INNER DOOR LABELS - NOT SHOWN
MODEL NUMBER 621 / 721 / 821
DESCRIPTION
QTY
REQ
PART NO.
ERROR CODE LABEL, VEC 12.1
1
1123715
PROGRAMMING LABEL, VEC 12.1
1
1123343
WIRING DIAGRAM LABEL, VEC 12.1/12.2
1
1127542
PRODUCT SET UP, V21
1
1126121
SPACE TO SALES, VEC 12.1
1
1128991
INNER DOOR LABEL
1
1125783-1
V21
Door Parts Trade ADA | D5-15
