SandenVendo V21 621 - Page 184

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230409
V21 TRADE LIVE DISPLAY OUTER DOOR - FLAT (CONTINUED)
ITEM
NO.
MODEL NUMBER
621
721
DESCRIPTION
QTY
REQ
PART NO.
QTY
REQ
PART NO.
1
DOOR WELD - BLACK (NON ADA)
1
1124879
1
1124890
DOOR WELD - BLACK (ADA)*
1
1217569
1
1217522
2
HOPPER ASSEMBLY (NON ADA)
1
1124157
1
1124157
HOPPER ASSEMBLY (ADA)*
1
133574
1
133574
3
SHEAR PANEL
1
1124932
1
1123915
4
BALLAST, U.S. 110V
1
1127582
1
1127582
5
COVER - SHEAR PANEL
1
1124844
1
1124844
6
INNER DOOR RAMP
1
1121714
1
1121714
7
COVER - CONTROLLER
1
1123049
1
1123049
8
PCBA VEC 12.1 CONTROLLER
1
1123051-12.1
1
1123051-12.1
9
STANDOFF
7
1121740
7
1121740
10
BRACKET - CONTROLLER
1
1127473
1
1127473
11
UPPER SHEAR PANEL
1
1124883
1
1124945
12
24” LAMP - T-8
24” LAMP – 24V LED
3
3
1121173
1237136-3
3
3
1121173
1237136
13
LAMP HOLDER FIXED
1
388531
1
388531
14
LAMP HOLDER BRACKET - FIXED
1
1124880
1
1124880
15
LAMP HOLDER PLUNGER
1
388352
1
388532
16
LAMP HOLDER BRACKET - PLUNGER
1
1124881
1
1124881
17
INNER DOOR HINGE - MALE
2
1121287
2
1121287
18
COIN MECH BRACKET ASSEMBLY
1
1124886
1
1124886
19
BARRIER PANEL
1
1148198
1
1148198
20
COIN BOX BULKHEAD
1
1112155
1
1112155
21
COIN BOX ASSEMBLY
1
1088058
1
1088058
22
EYELET – HOPPER (NON ADA)
1
1124101
1
1124101
EYELET – HOPPER (ADA)*
1
387125
1
387125
23
RAIN CURTAIN - BALLAST (NOT
SHOWN)
1 1125150 1 1125150
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
* ADA STYLE REFERS TO ALL MODEL NUMBERS XXXTALXXXXX.
V21 Door Parts Trade Live Display
| D6-5
