V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230409
V21 TRADE LIVE DISPLAY OUTER DOOR - CURVED
ITEM
NO.
MODEL NUMBER
721
DESCRIPTION
QTY
REQ
PART NO.
1
OUTER DOOR ASSEMBLY
1
*
2
DOOR WELD ASSEMBLY (NON ADA)
1
1124908
DOOR WELD ASSEMBLY (ADA)***
1
1217513
3
SIGN CAP - TOP
1
1014986
4
SIGN CAP - BOTTOM
1
1068988
5
SIDE TRIM - LEFT & RIGHT
2
1121981
6
BUTTON
10
1087074
7
SHELF
2
1124907
8
SUPPORT BRACKET - PRODUCT HOLDER CLIP
10
1124884
9
PRODUCT HOLDER CLIP
10
1120074
10
LAMP HOLDER BRACKET - PLUNGER
2
1124881
11
LAMP HOLDER PLUNGER
2
388532
12
LAMP HOLDER FIXED
2
388531
13
LAMP HOLDER BRACKET - FIXED
2
1124880
14
24” LAMP - T-8
2
1121173
LAMP, LED, 24”
2
1237136
15
PRICE LABEL BRACKET
2
1124894
16
OUTER DOOR SIGN FACE
1
**
17
3/8” FLAT WASHER - BOTTOM
2
V801491
18
BUSHING - HINGE
2
388094
19
DOOR ROLLER BRACKET
1
1120552
20
DOOR ROLLER
1
1120388
21
COIN RETURN CUP ASSEMBLY
1
1079546
22
DBV FILLER PLATE
1
390142
23
DBV PLUG
1
1086503
24
DBV PLUG GASKET
1
1086759
25
DBV FILLER PLATE GASKET
1
1120606
26
WATER COLLECTION TRAY
1
1110562
27
DRAIN TUBE
1
1110619
28
DOOR GUARD - 72”
1
2010131
29
RAIN GUARD
1
2000848
30
TRIM EYELET - CURVE
1
388271
31
T-8 ONLY LABEL (NOT SHOWN)
1
1122973
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
*NOTE: WHEN ORDERING OUTER DOOR ASSEMBLY, PLEASE PROVIDE 9-CODE OR 11-CODE
AND MANUFACTURER’S DATE CODE.
**NOTE: WHEN ORDERING SIGN FACE, PLEASE PROVIDE FRANCHISE, MODEL AND STYLE.
***ADA STYLE REFERS TO ALL MODEL NUMBERS XXXTALXXXXX.
V21 Door Parts Trade Live Display | D6-7
