SandenVendo V21 621 - Page 188

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230409
V21 TRADE LIVE DISPLAY OUTER DOOR - CURVED (CONTINUED)
ITEM
NO.
MODEL NUMBER
721
DESCRIPTION
QTY
REQ
PART NO.
1
DOOR WELD - BLACK (NON ADA)
1
1124908
DOOR WELD - BLACK (ADA)*
1
1217513
2
HOPPER ASSEMBLY (NON ADA)
1
1124162
HOPPER ASSEMBLY (ADA)*
1
1189115-3
3
SHEAR PANEL
1
1124931
4
BALLAST, U.S. 110V
1
1122380
5
INNER DOOR RAMP
1
1121714
6
COVER - CONTROLLER
1
1123049
7
PCBA VEC 12.1 CONTROLLER
1
1123051-12.1
8
STANDOFF
7
1121740
9
BRACKET - CONTROLLER
1
1124644
10
UPPER SHEAR PANEL
1
1124945
11
LAMP - 24” T-8
LAMP - 24” 24V LED
3
3
1121173
1237136
12
LAMP HOLDER FIXED
1
388531
13
LAMP HOLDER BRACKET - FIXED
1
1124880
14
LAMP HOLDER PLUNGER
1
388532
15
LAMP HOLDER BRACKET - PLUNGER
1
1124881
16
INNER DOOR HINGE - MALE
2
1121287
17
COIN MECH BRACKET ASSEMBLY
1
1124886
18
BARRIER PANEL
1
1117147
19
COIN BOX BULKHEAD
1
1112155
20
COIN BOX ASSEMBLY
1
133563
21
RAIN CURTAIN - BALLAST (NOT SHOWN)
1
1125150
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
*ADA STYLE REFERS TO ALL MODEL NUMBERS XXXTALXXXXX OR XXXTADXXXXX.
V21 Door Parts Trade Live Display
| D6-9
