V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230409
V21 TRADE LIVE DISPLAY INNER DOOR
ITEM
NO.
MODEL NUMBER
621
721
DESCRIPTION
QTY
REQ
PART NO. PART NO.
1
INNER DOOR ASSEMBLY
1
134302-80
134302-112
2
RAIN SEAL, INNER DOOR, 7”
1
1111732-1
1111732-2
3
INNER DOOR SEAL
1
1075678-2
1075678
4
UPPER PRODUCT RETAINER ASSEMBLY
1
1125206
1125206-1
5
UPPER PRODUCT RETAINER
1
1185778
1181827
6
SHORT CLIP ASSEMBLY
*
1125261
1125261
7
LONG CLIP ASSEMBLY
1
1125262
1125262
8
INNER DOOR HINGE, FEMALE
2
1121286
1121286
9
HINGE PIN
1
1172323
1172323
10
REVERSABLE VEND FLAP
1
1013076
1013076
11
INNER DOOR EYELET
1
387273
387273
12
GROMMET
1
388090
388090
13
INNER DOOR LATCH
1
1121711
1121711
14
INNER DOOR LATCH BRACKET
1
1121712
1121712
15
INNER DOOR GRAPHICS
1
**
**
16
RETAINER, GRAPHICS, SIDE
1
1125123-2
1125123-2
17
CORNER RETAINER, GRAPHICS
1
1124653
1124653
18
RETAINER, GRAPHICS, BOTTOM
1
1125123
1125123-1
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
*NOTE: QTY OF 9 FOR MODEL 721 & QTY 7 FOR MODEL 621
**NOTE: WHEN ORDERING INNER DOOR GRAPHICS, PLEASE PROVIDE FRANCHISE, MODEL
AND STYLE.
V21 TRADE LIVE DISPLAY INNER DOOR LABELS - NOT SHOWN
DESCRIPTION
QTY
REQ.
PART NO.
ERROR CODE LABEL, VEC 12.1
1
1123715
PROGRAMMING LABEL, VEC 12.1
1
1123343
WIRING DIAGRAM LABEL, VEC 12.1/12.2
1
1127542
PRODUCT SET UP, V21
1
1126121
SPACE TO SALES, VEC 12.1
1
1128991
INNER DOOR LABEL
1
1125783-1
V21 Door Parts Trade Live Display
| D6-13
