V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230417
HV3 INNER DOOR
ITEM NO.
MODEL NUMBER
721
821
DESCRIPTION
QTY REQ
PART NO.
PART NO.
1
INNER DOOR ASSEMBLY
1
134302-160
134302-161
2
RAIN SEAL, INNER DOOR, 7"
1
1111732-2
1111732-2
3
INNER DOOR SEAL
1
1075678
1075678-1
4
UPPER PRODUCT RETAINER ASSEMBLY
1
1185792-1
1185792-2
5
UPPER PRODUCT RETAINER
1
1181827
1181827-1
6
LONG CLIP RETAINER
1
1125202
1125202-1
7
INNER DOOR HINGE, FEMALE
2
1121286
1121286
8
HINGE PIN
1
1172323
1172323
9
REVERSABLE VEND FLAP
1
1013076
1013076
10
INNER DOOR EYELET
1
387273
387273
11
GROMMET
1
388090
388090
12
INNER DOOR LATCH
1
1121711
1121711
13
INNER DOOR LATCH BRACKET
1
1121712
1121712
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
HV3 INNER DOOR LABELS - NOT SHOWN
MODEL NUMBER 721 / 821
DESCRIPTION
QTY
REQ
PART NO.
ERROR CODE LABEL, VEC 12.3/V12.4
1
1170775
PROGRAMMING LABEL, VEC 12.4
1
1193696
WIRING DIAGRAM LABEL, VEC 12.1/12.2 1 1127542
PRODUCT SET UP, V21 1 1126121
SPACE TO SALES LABEL
1
1188767
INNER DOOR LABEL
1
1125783-1
WIRING SCHEMATIC, LED LIGHTING
1
1206035
V21 Door Parts HV3 ADA | D7-8
