V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230425
V21 HVV DOOR BACK
ITEM
NO.
MODEL NUMBER
621
721
821
DESCRIPTION
QTY
REQ
PART NO. PART NO. PART NO.
1
RAIN GUTTER
1
1121204
1121204
1121204
2
INNER DOOR HINGE, MALE
1
1121287
1121287
1121287
3
COIN RETURN ASSEMBLY
1
2006236-43
2006236-43
2006236-43
COIN RETURN PIVOT BRACKET
1121071
1121071
1121071
COIN RETURN CRANK
1121072
1121072
1121072
COIN INSERT SPRING
1060023
1060023
1060023
SHOULDER WASHER
1122715
1122715
1122715
4
COIN INSERT CHUTE
1
1121066
1121066
1121066
5
COIN BOX ASSEMBLY
1
1121124-1
1121124-1
1121124-1
6
COIN RETURN CHUTE SHIELD
1
1122615
1122615
1122615
7
COIN BOX HOUSING
1
1124376
1124376
1124376
8
HOPPER ASSEMBLY
1
1124162
1124162
1124162
9
DOOR WELD, 72”
1
~
1121120-3
~
DOOR WELD, 79”
1121120-5
~
1121120-4
10
LOWER HINGE HOOK
1
1121923
1121923
1121923
11
DOOR BUMPER (HEYCO 2551)
1
1036912
1036912
1036912
12
LOCK ASSEMBLY, HT2-TT *
1
1123073
1123073
1123073
13
TRITEQ LOCK LIGHT PIPE/SHROUD
1
1123640
1123640
1123640
14
LIGHT PIPE SHIELD
1
1123641
1123641
1123641
15
COIN RETURN CHUTE
1
1142809
1142809
1142809
16
INNER DOOR RAMP
1
1121714
1121714
1121714
17
DOOR ROLLER ASSEMBLY
1
1120564
1120564
1120564
18
DOOR ROLLER
1
1120388
1120388
1120388
19
DOOR ROLLER BRACKET
1
1239376
1239376
1239376
20
ELECTRONIC CONTROLLER COVER
1
1123529
1123529
1123529
21
VEC 12.3 PCBA
1
1123053-XX
1123053-XX
1123053-XX
22
DBV GASKET
1
1086759
1086759
1086759
23
DBV PLUG
1
388216-1
388216-1
388216-1
24
DBV INSERT (PLUG) BK
1
2000856
2000856
2000856
25
DOOR HARNESS (NOT PICTURED)
1
1122905
1122905
1122905
NOTE: T-HANDLE OPTION IS AVAILABLE FOR MODEL 621 ONLY. SEE PAGES PD-12 TO PD-13.
V21
Door Parts HVV | D8-5
