V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230247
V21 General Information | G-2
GENERAL INFORMATION
This manual contains programming, operation, and complete parts and electrical wiring
diagrams.
The V21 controller is a microprocessor which will permit pricing per selection from 0.00 to 99.99.
This machine also has space-to-sales programming as well as energy savings modes.
MODEL V21 521 V21 621 V21 721 V21 821
MAXIMUM SELECTIONS 7 8 10 10
DIMENSIONS (HEIGHT X WIDTH X DEPTH)*
CURVED DOOR 61” x 29” x 24” N/A 72” X 39.5” X 35” 79” X 39.5” X 35”
FLAT DOOR N/A 72” X 32.5” X 34.5” 72” X 39.5” X 32.5” N/A
SINGLE COLUMNS 7 8 10 10
CAPACITY PER
COLUMN
12oz.
CAN***
16oz. GLASS
20oz. PET **
26
13
13
68
28
30
68
28
30
80
34
36
SHIPPING WEIGHT* 365 lbs. 640 lbs. 685 lbs. 750 lbs.
OPERATION VOLTAGE 115V 60Hz 115V 60Hz 115V 60Hz 115V 60Hz
AMP. RATING 4 8 8 8
REFRIGERATION VOLTAGE 115V 60Hz 115V 60Hz 115V 60Hz 115V 60Hz
*Dimensions and shipping weight will vary slightly due to manufacturing tolerances, shipping
boards and whether or not coinage is installed.
** 20 oz. PET capacity may vary based on the shape and size of the bottle.
***12 oz. can capacities are listed using a 4-deep set up.
