V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230425
V21 HVV INNER DOOR
ITEM
NO.
MODEL NUMBER
721
821
DESCRIPTION
QTY
REQ
PART NO. PART NO.
1
INNER DOOR ASSEMBLY
1
134302-126
134302-127
2
RAIN SEAL, INNER DOOR, 7"
1
1111732-2
1111732-2
3
INNER DOOR SEAL
1
1075678
1075678-1
4
UPPER PRODUCT RETAINER ASSEMBLY
1
1125206-1
1125206-2
5
UPPER PRODUCT RETAINER
1
1181827
1181827-1
6
SHORT CLIP ASSEMBLY
9
1125261
1125261
7
LONG CLIP ASSEMBLY
1
1125262
1125263
8
INNER DOOR HINGE, FEMALE
2
1121286
1121286
9
HINGE PIN
1
1172323
1172323
10
REVERSABLE VEND FLAP
1
1013076
1013076
11
INNER DOOR EYELET
1
387273
387273
12
GROMMET
1
388090
388090
13
INNER DOOR LATCH
1
1121711
1121711
14
INNER DOOR LATCH BRACKET
1
1121712
1121712
V21 HVV INNER DOOR LABELS - NOT SHOWN
DESCRIPTION
QTY
REQ
PART NO.
WARNING/PATENTS, U.S. OR
WARNING/PATENTS, INTL.
1
1125783-1
1125783
ERROR CODE LABEL, VEC 12.3
1
1123717
PROGRAMMING LABEL, VEC 12.3 1 1123345
WIRING DIAGRAM LABEL, VEC 12.3 1 1127541
PRODUCT SET UP, V21
1
1126121
SPACE TO SALES, VEC 12.3
1
1123311
V21
Door Parts HVV | D8-15
