SandenVendo V21 621 - Page 218

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230433
V21 HVV ADA DOOR FRONT
ITEM
NO.
MODEL NUMBER
621
721
821
DESCRIPTION
QTY REQ
PART NO.
PART NO.
PART NO.
1
UPPER SIGN FACE **
1
**
**
**
2
LOWER SIGN FACE **
1
**
**
**
3
UPPER SIGN CAP, BLUE
1
1127305-1
1114341-2
1114341-2
UPPER SIGN CAP, GREEN
1127305-2
1114341-4
1114341-4
UPPER SIGN CAP, BLACK
1127305
1114341
1114341
4
LOWER SIGN CAP, BLUE
1
1127510-1
1114341-3
1114341-3
LOWER SIGN CAP, GREEN
1127510-2
1114341-5
1114341-5
LOWER SIGN CAP, BLACK
1127510
1114341-1
1114341-1
5
UPPER / MIDDLE SIGN CAP, BLUE
1
1122769
1121063
1121063
UPPER / MIDDLE SIGN CAP, GREEN
1122769-1
1121063-1
1121063-1
UPPER / MIDDLE SIGN CAP, BLACK
N/A
1121063-2
1121063-2
6
LOWER / MIDDLE SIGN CAP, BLUE
1
1122768
1121060
1121060
LOWER / MIDDLE SIGN CAP, GREEN
1122768-1
1121060-1
1121060-1
LOWER / MIDDLE SIGN CAP, BLACK
N/A
1121060-2
1121060-2
7
UPPER SIGN TRIM, 72”, BLUE
2
1121100-1
1121100-13
~
UPPER SIGN TRIM, 79”, BLUE
~
~
1121100-14
UPPER SIGN TRIM, 72”, GREEN
N/A
1121100-16
~
UPPER SIGN TRIM, 79”, GREEN
N/A
~
1121100-17
UPPER SIGN TRIM, 72”, BLACK
N/A
1121100-10
~
UPPER SIGN TRIM, 79”, BLACK
N/A
~
1121100-11
8
LOWER SIGN TRIM, 72” & 79”, BLUE
2
1121100
1121100-12
1121100-12
LOWER SIGN TRIM, 72” & 79”, GREEN
N/A
1121100-15
1121100-15
LOWER SIGN TRIM, 72” & 79”, BLACK
~
1121100-9
1121100-9
9
RAIN GUARD (BLUE)
1
2005937
2005872
2005872
RAIN GUARD (GREEN)
2005937-1
2005872-01
2005872-01
RAIN GUARD (BLACK)
N/A
2000848
2000848
10
DOOR GUARD, 72”, BLUE
1
1122179
1122179
~
DOOR GUARD, 79”, BLUE
~
~
1122179-1
DOOR GUARD, 72”, GREEN
N/A
1122179-2
~
DOOR GUARD, 79”, GREEN
N/A
~
1122179-3
DOOR GUARD, 72”, BLACK
N/A
2010131
~
DOOR GUARD, 79”, BLACK
N/A
~
2009503
11
SELECTION PANEL (SEE PAGE D-7)
~
~
~
~
12
LOWER CONSUMER PANEL, WITHOUT KEY
1
1121064-4
1121064-4
1121064-4
13
UPPER CONSUMER PANEL
1
1121084-11
1121084-11
1121084-11
-WITHOUT DBV
1121084-8
1121084-8
1121084-8
-WITHOUT DBV, CA FRENCH
1121084-8
1121084-8
1121084-8
-LARGE DBV
1121084-11
1121084-11
1121084-11
-UNIVERSAL LANGUAGE
1121084-7
1121084-7
1121084-7
-UNIVERSAL LANG., WITHOUT DBV
1121084-8
1121084-8
1121084-8
-UNIVERSAL LANG., WITHOUT DBV, LARGE COIN
1121084-9
1121084-9
1121084-9
-UNIVERSAL LANG., LARGE DBV, LARGE COIN
1121084-10
1121084-10
1121084-10
-UNIVERSAL LANG., LARGE DBV
1121084-11
1121084-11
1121084-11
14
SELECTION SPRING
1
1029959
1029959
1029959
15
COIN RETURN BUTTON
1
1050473
1050473
1050473
16
DISPLAY LENS
1
1121103
1121103
1121103
17
SERIAL DISPLAY, 2 X 20
1
1137414
1137414
1137414
18
EYELET TRIM
1
1121102
1121102
1121102
19
HINGE BUSHING
2
388094
388094
388094
20
PEPSI LOGO DECAL **
1
**
**
**
AQUAFINA LOGO DECAL **
**
**
**
MOUNTAIN DEW LOGO DECAL **
**
**
**
GATORADE LOGO DECAL **
**
**
**
*NOTE: WHEN ORDERING OUTER DOOR ASSEMBLY, PLEASE PROVIDE 9-CODE OR 11-CODE AND MANUFACTURER’S DATE
CODE.
**NOTE: WHEN ORDERING SIGN FACE, PLEASE PROVIDE FRANCHISE AND STYLE.
V21 HVV ADA Trade Door Section | D9-3
