SandenVendo V21 621 - Page 220

V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230433
V21 HVV ADA DOOR BACK
ITEM
NO.
MODEL NUMBER
621
721
821
DESCRIPTION
QTY
REQ
PART NO. PART NO. PART NO.
1
RAIN GUTTER
1
1121204
1121204
1121204
2
INNER DOOR HINGE, MALE
1
1121287
1121287
1121287
3
COIN RETURN ASSEMBLY
1
2006236-43
2006236-43
2006236-43
COIN RETURN PIVOT BRACKET
1121071
1121071
1121071
COIN RETURN CRANK
1121072
1121072
1121072
COIN INSERT SPRING
1060023
1060023
1060023
SHOULDER WASHER
1122715
1122715
1122715
4
COIN INSERT CHUTE
1
1121066
1121066
1121066
5
COIN BOX ASSEMBLY
1
1121124-1
1121124-1
1121124-1
6
COIN CHUTE, UPPER
1
1200007
1200007
1200007
7
COIN BOX HOUSING
1
1199961
1199961
1199961
8
HOPPER ASSEMBLY
1
1189115
1189115
1189115
9
DOOR BUMPER (HEYCO 2551)
1
1036912
1036912
1036912
10
LOCK ASSEMBLY, HT2-TT *
1
1123073
1123073
1123073
11
TRITEQ LOCK LIGHT PIPE/SHROUD
1
1123640
1123640
1123640
12
LIGHT PIPE SHIELD
1
1199017
1199017
1199017
13
COIN RETURN CHUTE
1
1142809
1142809
1142809
14
INNER DOOR RAMP
1
1121714
1121714
1121714
15
DOOR ROLLER ASSEMBLY
1
1120564
1120564
1120564
16
DOOR ROLLER
1
1120388
1120388
1120388
17
DOOR ROLLER BRACKET
1
1239376
1239376
1239376
18
ELECTRONIC CONTROLLER COVER
1
1123529
1123529
1123529
19
VEC 12.3 PCBA
1
1123053-XX
1123053-XX
1123053-XX
20
DBV GASKET
1
1086759
1086759
1086759
21
DBV PLUG
1
388216-1
388216-1
388216-1
22
DBV INSERT (PLUG) BK
1
2000856
2000856
2000856
23
COIN BOX CHUTE, LOWER
1
1200033
1200033
1200033
24
DOOR HARNESS (NOT PICTURED)
1
1122905
1122905
1122905
NOTE: T-HANDLE OPTION IS AVAILABLE FOR MODEL 621 ONLY. SEE PAGES PD-12 TO PD-13.
V21 HVV
ADA Trade Door Section | D9-5
