V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230433
V21 HVV ADA SELECTION PANEL ASSEMBLY
ITEM
NO.
MODEL NUMBER
621
721 / 821
DESCRIPTION
QTY
REQ
PART NO. PART NO.
1
BUTTON ASSEMBLYS:
RIGHT PANEL ASSEMBLY, 6 SELECTION, BLUE
2
N/A
1122613
LEFT PANEL ASSEMBLY, 6 SELECTION, BLUE
2
N/A
1122613-1
SOLD OUT/READY TO VEND ASSY, RIGHT, 6 SEL, BLUE
2
N/A
1122613-2
SOLD OUT/READY TO VEND ASSY, LEFT, 6 SEL, BLUE
2
N/A
1122613-3
RIGHT PANEL ASSEMBLY, 6 SELECTION, GREEN
2
N/A
1122613-6
LEFT PANEL ASSEMBLY, 6 SELECTION, GREEN
2
N/A
1122613-7
SOLD OUT/READY TO VEND ASSY, RIGHT, 6 SEL, GREEN
2
N/A
1122613-8
SOLD OUT/READY TO VEND ASSY, LEFT, 6 SEL, GREEN
2
N/A
1122613-9
RIGHT PANEL ASSEMBLY, 6 SELECTION, BLACK
2
N/A
1122613-20
LEFT PANEL ASSEMBLY, 6 SELECTION, BLACK
2
N/A
1122613-21
SOLD OUT/READY TO VEND ASSY, RIGHT, 6 SEL, BLACK
2
N/A
1122613-22
SOLD OUT/READY TO VEND ASSY, LEFT, 6 SEL, BLACK
2
N/A
1122613-23
RIGHT PANEL ASSEMBLY, 3 SELECTION, BLUE
2
1122613-4
N/A
LEFT PANEL ASSEMBLY, 3 SELECTION, BLUE
2
1122613-5
N/A
RIGHT PANEL ASSEMBLY, 3 SEL, T-HANDLE OPTION, BLUE
2
1122613-24
N/A
2
BUTTON PANEL, BLUE
2
1122884
1121121
BUTTON PANEL, T-HANDLE, BLUE (RIGHT SIDE ONLY)
1
1122884-2
N/A
BUTTON PANEL, GREEN
2
1122884-1
1121121-01
BUTTON PANEL, BLACK
2
N/A
1121121-03
3
FLAVOR LABEL
**
**
**
4
SELECTION BUTTON
A/R
1121057
1121057
5
BUTTON RETAINER SWITCH MOUNT, 6 SEL
8
N/A
1121070
BUTTON RETAINER SWITCH MOUNT, 3 SEL
4
1122619
N/A
BUTTON RETAINER SWITCH MOUNT, 3 SEL, T-HANDLE
4
1126109
N/A
6
FLAT SPRING
A/R
1122622
1121112
7
2-TERMINAL SWITCH
A/R
1120885
1120885
8
LIGHT PIPE SHIELD
1
1199017
1199017
9
T-HANDLE LOCK ASSEMBLY (SEE PAGES PD-12 TO PD-13)
~
~
~
**NOTE: WHEN ORDERING FLAVOR LABELS, PLEASE PROVIDE FRANCHISE AND STYLE.
V21 HVV
ADA Trade Door Section | D9-11
