V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230433
V21 HVV T-HANDLE ASSEMMBLY
ITEM
NO.
DESCRIPTION
QTY
REQ
PART NO.
1
LOCK COVER PLATE, BLUE
1
1126568
2
LOCK SHIELD
1
1126218
3
LOCK STUD COVER
1
1121817-1
4
T-HANDLE LOCK ASSEMBLY
1
1126557
5
T-HANDLE
1
1002392
6
SPRING
1
389691
7
E-RING RETAINER
2
388589
8
HEX WASHER
1
387600
9
FLANGE
1
1002384
10
LOCK STUD
1
1122399
11
PIN, LOCK STUD
1
387601
12
SPRING QUICKER LOCK
1
389690
13
WASHER
1
387718
V21 HVV
ADA Trade Door Section | D9-13
