V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230433
V21 HVV ADA INNER DOOR
ITEM
NO.
MODEL NUMBER
621
721
821
DESCRIPTION
QTY
REQ
PART NO. PART NO. PART NO.
1
INNER DOOR ASSEMBLY
1
134302-170
134302-168
134302-169
2
RAIN SEAL, INNER DOOR, 7"
1
1111732-2
1111732-2
1111732-2
3
INNER DOOR SEAL
1
1075678-2
1075678
1075678-1
4
UPPER PRODUCT RETAINER ASSEMBLY
1
1185792
1185792-1
1185792-2
5
UPPER PRODUCT RETAINER
1
1185778
1181827
1181827-1
6
SHORT CLIP ASSEMBLY
2
1125201
1125201
1125201
7
LONG CLIP ASSEMBLY
1
1125202
1125202
1125202-1
8
INNER DOOR HINGE, FEMALE
2
1121286
1121286
1121286
9
HINGE PIN
1
1172323
1172323
1172323
10
REVERSABLE VEND FLAP
1
1013076
1013076
1013076
11
INNER DOOR EYELET
1
387273
387273
387273
12
GROMMET
1
1123629
1123629
1123629
13
INNER DOOR LATCH
1
1121711
1121711
1121711
14
INNER DOOR LATCH BRACKET
1
1121712
1121712
1121712
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-15.
V21 HVV ADA INNER DOOR LABELS - NOT SHOWN
MODEL NUMBER
621 / 721 / 821
DESCRIPTION
QTY
REQ
PART NO.
ERROR CODE LABEL, VEC 12.1
1
1170775
PROGRAMMING LABEL, VEC 12.1
1
1123345
WIRING DIAGRAM LABEL, VEC 12.1/12.2
1
1127541
PRODUCT SET UP, V21
1
1126121
SPACE TO SALES, VEC 12.1
1
1123311
INNER DOOR LABEL
1
1125783-1
V21 HVV
ADA Trade Door Section | D9-15
