Diagnostics:
See inner door of vendor or Troubleshooting section for errors and how to clear them.
Coin Payout:
Coin Payout Mode allows the operator to ‘test’ for proper operation of the changer tubes.
1. Press Button 4 to enter into “Coin Payout” mode.
2. Press Button 2 or 3 to scroll to desired denomination.
3. Press Button 4 to dispense displayed denomination.
4. Press Button 1 to exit mode.
Tube Fill:
Allows you to fill coin tubes via the external coin insert. This is the recommended way to fill the
coin tubes because the control board is able to keep an accurate count of the coins.
1. Press Button 4 to enter into “Tube Fill” mode.
2. Insert coins into coin insert slot and the controller will “count” the number of coins going
into the coin mechanism.
Test Mode:
Allows you to test vend a column, jog a column, test selection switches, display, refrigeration
system, lights, and heater.
Vending a Column:
1. At “Test Mode”, press Button 4. Display will read –“Test Mode – Vending”
2. Press Button 4 to enter – the display will read “Column 1”.
3. Press Button 2 or Button 3 to scroll to the desired column.
4. Press Button 4 to vend.
a. If motor vends OK, DISPLAY will read “Test Mode - Vending Motor OK”
b. If motor does not test OK on one of the following messages will appear:
- “Test Mode - Vending Fail - Column Jam”
- “Test Mode - Vending Fail - No Connection”
- “Test Mode - Vending Fail - High Current”
Jogging a Column:
Allows you to test the column in forward and reverse direction.
1. At “Test Mode” press Button 4.
2. Press Button 2 or 3 to scrollto “Test Mode - Jog.”
3. Press Button 4 and display will read “Column 1.”
4. Press Button 2 or 3 to scroll to desired column.
5. Press Button 4 to enter into column and display will read “Column X Forward” with X
being the desired column.
6. Press Button 2 or 3 to scroll between “Forward” or “Reverse.”
7. Press Button 4 to move/jog the motor in the desired position.
8. Press Button 1 to exit this mode.
V21
12.4 Programming HV3 / CHAMELEON | P1-3
