To set the clock:
1. Press Button 4 at the “Set Clock” prompt. You will be able to scroll through the following
options by pressing Button 2 or 3.
- Enable ON/OFF - This will turn the clock timer on or off.
- MM/DD/YYYY HH:MM - This is the current time and date.
- Daylight Savings
2. Press Button 4 to change current setting. The current setting will begin to flash.
3. Press Button 2 or 3 to change current setting.
4. Press Button 4 to save current setting.
Lighting:
If the “Timing Features” in the “Configuration” mode are turned ON, you will have access to
this mode. This mode allows you to turn the lights on/off with the internal timer.
1. Press Button 4 when the display reads “Start Time 1” or “Start Time 2.”
2. Press Button 4 at “Start Time 1” or “Start Time 2.”
3. Press Button 4 at “Start Day 1” or “Start Day 2.”
4. Scroll through the days of the week or “all” with Button 2 or 3.
5. Press Button 4 to change current setting.
6. Change setting by pressing Button 2 or 3.
7. Press Button 4 to save changes.
8. Press Button 2 or 3 at “Start 100.00” or “Start 200.00”
9. Press Button 4 to change time.
10. Press Button 2 or 3 to set time.
11. Press Button 4 to save.
12. Press Button 1 to exit mode.
13. Repeat process with “Stop Time 1” or “Stop Time 2.”
Refrigeration:
If ‘Timing Features’ in Configuration Mode are ‘Off’, you will only have access to the following
features:
Set Point Temperature
Sensor Reading
Degree Setting
Fan Energy Mode
Periodic Defrost Mode
To change the set point temperature:
1. Press Button 4 when the display reads “Refrigeration.”
2. The display will read “Set Point XX” with the current setting displayed.
3. To change the setting press Button 4 and the current set point temperature will begin to flash.
4. Press Button 2 or 3 to increase or decrease the set point.
V21 12.4 Programming HV3 / CHAMELEON | P1-9
