V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230298
THREE-BUTTON PROGRAMMING
All programming of the V21 control board is done in the service mode. To enter the service
mode open the vendor door, find the service mode button located on the control board, then
press and release the service mode button. To scroll through all the service modes, use selection
button one.
The first three selection buttons are used to navigate through the programming as follows:
Button Description Usage
Selection Button 1 Up/Down Increase/Decrease, Next/Previous
Selection Button 2 Enter Go to sub-level, activate function
Selection Button 3 Exit Return to previous level, exit, save
FIGURE 1
The controller will automatically return to the Open-Door Sales Mode if:
1. No information from the selection switches is received within approximately 30 seconds.
2. The service mode button is pressed a second time.
3. The (Exit) button is pressed.
When the programming is entered, any established credit is returned. When and if the door is
closed, the controller will exit the service mode and return to the sales mode.
MIS Data
As soon as the outer door is opened, the non-resettable MIS data will be displayed if no errors
exist. “
CAns XXX” will flash for approximately 30 seconds, indicating the total number of units
the machine has sold. After 30 seconds, “
CASh XX.XX” will begin to scroll, indicating the total
dollar amount the machine has accumulated. NOTE: Pressing selection button one will eliminate
the 30-second wait time and advance you immediately to the “
CASh XX.XX” scroll.
To access MIS data by individual selection, press selection button two during the “
CAnS XXXX”
or “
CASh XX.XX” scroll. Use selection button one to advance forward or backward through the
selections. Please see page PG-7 to choose between count by selection and count by price.
NOTE: The MIS data that is displayed when the outer door is opened (“
CAnS XXXX” and CASh
XX.XX”) is non-resettable. This data is accumulated over the life of the control board and can
only be changed by replacing the control board.
V21
12.1 Programming Trade | P3-3
