V21 Parts & Service Manual
All V21 Identified Equipment
REV A – 10/2013
P/N: 1230328
VEC 12.3 CONTROL BOARD OPERATIONS
NOTE: Some units may contain a European font display, in which case the “°” symbol will
be replaced by the “ß” symbol. Example: 72°F will be 72 ß F.
The VEC 12.3 Controller uses a 3-button programming system:
Row 1 (all selection buttons in top row) – Increase/Decrease
Row 2 (all selection buttons in top row) – Enter and/or Save
Row 3 (all selection buttons in top row) – Escape/Exit
In order to access Mode functions, open the door. Locate the Mode Button. Press the mode
button one time. Row 1 will take you through the modes.
The available modes are:
Diagnostics
Coin Payout
Tube Fill
Test Mode
Cash Data
Sales Data
Set Price
Set Depth
Configuration
Space to Sales
Door Closed Password
Set Language
Set Clock *
Lighting *
Refrigeration **
Sales Block 1 *
Sales Block 2 *
Discount *
Override **
Return
* These modes will only appear when the “Timing Features” in Configuration are turned ON.
** Limited options appear in these modes depending on whether the Timing Features are
ON/OFF.
V21 12.3
Programming HVV | P4-2
