SanDisk CompactFlash Card OEM Product Manual CIS Description
Table 6-1 Card Information Structure
Attribute
Offset Data 7 6 5 4 3 2 1 0 Content Description
CIS
Function
146h 21h X
0
R
0
P
1
RO
0
A
0
T
1
Power-Down,
and Twin Card.
TPCE_MI
T: Twin Cards Allowed
A: Audio Supported
RO: Read Only Mode
P: Power Down
Supported
R: Reserved
X: More Misc Fields
Bytes
148h 1Bh CISTPL_CE Configuration
Entry Tuple
Tuple Code
14Ah 06h Link to Next Tuple is 6 Link to
Bytes. Also limits size of Next Tuple
this tuple to 8 bytes.
14Ch 03h I D Configuration Index AT Fixed Disk TPCE_INDX
0 0 3
Secondary I/O
3.3V Configuration
14Eh 01h M MS IR IO T P P: Power Info type TPCE_FS
0 0 0 0 0 1
150h 21h R
0
DI
0
PI
1
AI
0
SI
0
HV
0
LV
0
NV
1
PI: Peak Current
NV: Nominal Operation
Supply Voltage
Power
Parameters
for V
CC
152h B5h X Mantissa Exponent Nominal Operation Nominal
1 6h = 3.0 5h = 1
Supply Voltage = 3.0V Operation
Supply
Voltage
154h 1Eh X 1Eh 0.3 Nominal
0
Operation
Supply
Voltage
Extension
Byte
156h 4Dh X Mantissa Exponent Max. Average Current Max. Average
0 9h = 4.5 5h = 10
over 10 ms is 45 mA Current
158H 1Bh CISTPL_CE Configuration
Entry Tuple
Tuple Code
15Ah 04h Link to Next Tuple Link to
is 4 bytes Next Tuple
15Ch 07h I D Configuration Index AT Fixed Disk TPCE_INDX
0 0 7
Secondary I/O
3.3V Configuration
15Eh 00h M MS IR IO T P P: Power Info type TPCE_FS
0 0 0 0 0 0
160h 028h SanDisk Code Reserved
162h 0D3h SanDisk Code Reserved
© 2007 SanDisk Corporation 6-17 Rev. 12.0, 02/07
