Product Specifications SanDisk CompactFlash Card OEM Product Manual
Sleep mode currently is specified under the condition that all card inputs are static CMOS
levels and in a "Not Busy" operating state.
Table 2-2 Power Requirements
DC Input Voltage (Vcc)
100 mV max. ripple (p-p) 3.3V +/- 5% 5V +/- 10%
Memory Subsystem
a
CompactFlash Memory Card
Sleep
Up to 512 MB 300
µ 500 µ
1.0 GB 600 µ 800 µ
Over 1.0 GB 1 mA 1.2 mA
Read 50 mA 55 mA
Write 65 mA 70 mA
Read/Write Peak 100 mA 100 mA
Memory Subsystem
a
CompactFlash Extreme III Memory Card
Sleep
Up to 512 MB
512 MB to 1.5 GB
Over 1.5 GB
300
µ
600 µ
1 mA
500 µ
800 µ
1.2 mA
Read 75 mA 100 mA
Write 75 mA 100 mA
Read/Write Peak 100 mA 100 mA
a. Maximum average value.
