Interface Description SanDisk CompactFlash Card OEM Product Manual
PC Card I/O Pin Assignments are contained in Table 3-2.
Table 3-2 PC Card I/O Mode Pin Assignments
Pin No.
Signal
Name Pin Type I/O Type Pin No.
Signal
Name Pin Type I/O Type
1 GND – Ground 26 -CD1 O Ground
2 D03 I/O I1Z,OZ3 27 D11 I/O I1Z,OZ3
3 D04 I/O I1Z,OZ3 28 D12 I/O I1Z,OZ3
4 D05 I/O I1Z,OZ3 29 D13 I/O I1Z,OZ3
5 D06 I/O I1Z,OZ3 30 D14 I/O I1Z,OZ3
6 D07 I/O I1Z,OZ3 31 D15 I/O I1Z,OZ3
7 -CE1 I I3U 32 -CE2 I I3U
8 A10 I I1Z 33 -VS1 O Ground
9 -OE I I3U 34 -IORD I I3U
10 A09 I I1Z 35 -IOWR I I3U
11 A08 I I1Z 36 -WE I I3U
12 A07 I I1Z 37 -IREQ O OT1
13 VCC – Power 38 VCC – Power
14 A06 I I1Z 39 -CSEL I I2Z
15 A05 I I1Z 40 -VS2 O OPEN
16 A04 I I1Z 41 RESET I I2Z
17 A03 I I1Z 42 -WAIT O OT1
18 A02 I I1Z 43 -INPACK O OT1
19 A01 I I1Z 44 -REG I I3U
20 A00 I I1Z 45 -SPKR I/O I1U,OT1
21 D00 I/O I1Z,OZ3 46 -STSCHG I/O I1U,OT1
22 D01 I/O I1Z,OZ3 47 D08 I/O I1Z,OZ3
23 D02 I/O I1Z,OZ3 48 D09 I/O I1Z,OZ3
24 -IOIS16 O OT3 49 D10 I/O I1Z,OZ3
25 -CD2 O Ground 50 GND – Ground
True IDE Mode Pin Assigments are contained in Table 3-3.
Table 3-3 True IDE Mode Pin Assignments
Pin
No.
Signal
Name Pin Type I/O Type Pin No.
Signal
Name Pin Type I/O Type
1 GND – Ground 26 -CD1 O Ground
2 D03 I/O I1Z,OZ3 27 D11 I/O I1Z,OZ3
3 D04 I/O I1Z,OZ3 28 D12 I/O I1Z,OZ3
4 D05 I/O I1Z,OZ3 29 D13 I/O I1Z,OZ3
5 D06 I/O I1Z,OZ3 30 D14 I/O I1Z,OZ3
6 D07 I/O I1Z,OZ3 31 D15 I/O I1Z,OZ3
7 -CS0 I I3Z 32 -CS1 I I3Z
8 A10 I I1Z 33 -VS1 O Ground
02/07, Rev. 12.0 3-2 © 2007 SanDisk Corporation
