SanDisk CompactFlash Card OEM Product Manual CIS Description
Table 6-1 Card Information Structure
Attribute
Offset Data 7 6 5 4 3 2 1 0 Content Description
CIS
Function
12Ah 27h R DI PI AI SI HV LV NV Nominal Voltage Follows
Power
0 0 1 0 0 1 1 1 NV: Nominal Voltage
LV: Mimimum Voltage
Parameters
for V
CC
HB: Maximum Voltage
SI: Static Current
AI: Average Current
PI: Peak Current
DI: Power Down Current
12Ch 55h X Mantissa Exponent V
CC
Nominal is 5V V
CC
Nominal
0 Ah = 5.0 5h = 1V
Value
12Eh 4Dh X Mantissa Exponent V
CC
Nominal is 4.5V V
CC
Min.
0 9h = 4.5 5h = 1V
Value
130h 5Dh X Mantissa Exponent V
CC
Nominal is 5.5V V
CC
Max.
0 Bh = 5.5 5h = 1V
Value
132h 75h X
0
Mantissa
Eh = 1.0
Exponent
5h = 10
Max. Average Current
over 10 ms is 80 mA
Max. Average
Current
134h EAh R
1
S
1
E
1
IO AddeLines
Ah = 10
Supports both 8- and
16-bit I/O hosts. 10
Address Lines with
TPCE_IO
Range so card will
respond only to
indicated (170-177, 376-
377) on A9 through A0
for I/O cycles. IO
AddrLines:#lines
decoded
E: 8-bit Only Hosts
Supported
S: 16-bit Hosts
Supported
R: Range follows
© 2007 SanDisk Corporation 6-15 Rev. 12.0, 02/07
