sufficient air intakes to assure
adequate combustion.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance in
a safe way and understand the
hazards involved. Children shall not
play with the appliance. Cleaning
and user maintenance shall not be
made by children without
supervision
Safety during installation.
Fan unit equipment should be
electrically isolated and locked out
before any work started.
The Installer, User is responsible for
ensuring that the fan unit is installed,
operated and serviced by qualified
personnel, acting in accordance with all
safety precautions applicable and as
required by law, regulations and standards
in the country applicable.
Safety protective clothing, equipment,
hearing protection, and tools may be
required.
Before any installation work is started,
ensure that fan unit equipment is correct
for application. Location for installation is
solid, level, flat and suitable for mounting
fan unit assembly.
Fan unit should be located in position, and
assembled with any accessory equipment
supplied, on relevant mounting, anti-
vibration mountings, safety protection
guards, on a solid level base to avoid any
distortion and misalignment and with
correct air direction as shown on
nameplate. Fan unit should then be
levelled on any anti-vibration mountings.
Flexible connectors must be taught to
ensure no disruption to air flow, especially
on inlet to fan unit.
Make sure there are no loose elements
near the fan unit. When the fan unit is
mounted in a duct, check that it is clean of
any elements and exclusively used for
ventilation system.
The electrical installation must include a
double pole switch with a contact
clearance of at least 3 mm, correctly sized
and in accordance with the electrical
standards of the country of installation.
For electrical connections follow the wiring
diagram “A” indicated in this manual.
The fan unit classified as Residential
Ventilation Unit with control factor 0,65
have to comply with the requirements of
the European Directive 2009/125 and
must be installed following the local
demand control definition given in the
regulation nº1253/2014 (See fig.B as
example).
Start up.
Check fan unit equipment name plate data
is appropriate to the location electrical
supply, especially Voltage, Frequency,
Phase, Amps, speed are correct.
Check earth connections, electrical
terminations and terminal box lid, with any
seals, if fitted, are correct.
In compliance with Machine Directive, if the
fan unit is accessible to operators and is a
health and safety risk, adequate protection
must be fitted, information for safety
equipment, including guards, can be found
in S&P accessories catalogue.
Check all rotating parts have free,
unobstructed movement.
Check there are no foreign bodies inside
the fan unit or that can be drawn into, or fall
into fan unit.
