11
EDM model EC
This model is equipped with a photoelectric cell that
activates the extractor when the light intensity is greater
than 30 Lux. Therefore, to avoid the fan working
continuously, these models must be installed only in rooms
with poor illumination. As an indication, an intensity of 30
Lux is to low to allow normal reading ( Fig. 12).
EDM models M,VM and VMH
Models fitted with pullcord switch
EDM-100 M and VM : Fig. 13.
EDM-100 VMH see the explanation for models H,CH and
VMH.
EDM models VM and VMH. Installation (Fig. 14)
These models have been designed for installation on
window (single or double glazing) or wall.
1 and 10 : Protection grille 6 : Outlet
2 : Cable entry 7 : Rubber joints
3 : Connection cover 8 : Spacers
4 : Fixing screw 9 : Threaded ring
5 : Connection terminals
For the installation, make a hole of 105 mm diameter in the
glazing or on the wall.
Loosen the screws on the front and back protection grilles
(1 and 10). Loosen the threaded ring (9) and remove the 4
spacers (8).
Mount the EDM depending on the installation requirements
so the glass or the wall is between the two rubber joints (7):
Fig. 5a : All the spacers on the outside
Fig. 5b : All the spacers on the inside
Fig. 5c : Spacers both on the outside and the inside
When the unit is installed in double glazing or on a wall, it is
possible that all the spacers are not needed.
Once the above operations are finished, fix the EDM with
the threaded ring, make the electrical connection and
mount again the protection grilles.
User instruction
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experienceand knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance.Cleaning and user maintenance
shall not be made by children without supervision.
Maintenance
The extractor needs only a periodical cleaning using a cloth
lightly impregnated with a soft detergent.
After Sales Service
We recommend you not to try to dismantle or remove any
other parts than those mentioned as any tampering would
automatically cancel the S&P guarantee. If you detect any
fault, contact your S&P dealer.
S&P reserves the right to alter specifications without notice
