7
– The HCM series of fans are designed for general ventilation use
only. Do Not Use To Extract Hazardous or Potentially Explosive
Materials and Vapours.
– This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the applian-
ce in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenan-
ce shall not be made by children without supervision.
– Children of less than 3 years should be kept away unless conti-
nuously supervised.
– Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been placed or
installed in its intended normal operating position and they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
– Children aged from 3 years and less than 8 years shall not plug
in, regulate and clean the appliance or perform user mainte-
nance.
– Children shall not play with the appliance.
INSTALLATION
Before any installation ensure the fan is isolated and disconnected from the mains electrical
supply.
MOUNTING THE FAN IN GLASS OR A PANEL
(Maximum thickness 8 mm)
– First cut a circular hole in the glass or panel in which the fan is to be installed. Cut the hole
size in accordance with the HCM model size as indicated in Figure (A1).
– Figure (B). Remove the interior grille (1) from the fan casing by loosening the fi xing screw
(3).
– Remove the exterior grille (with shutters) by removing the interior plastic fi xing nuts (6).
– Separate the fan casing (3) from the exterior grille (2).
