IMPORTANT NOTE: The instructions and safety warning appearing in this
instructions manual do not intend to cover all the possible situations and
conditions that could occur. It should be understood that common sense,
care and precaution are factors to be taken into consideration. These
factors are the responsibility of those who maintain and operate the fan.
(Fig.1)
IMPORTANT NOTE:
2.30
metros.
(minimum 50 Kgs).
(Fig.2A)
Note:
50kg.
UNPACKING INSTRUCTIONS
INSTALLATION INSTRUCTIONS
HANGING THE CEILING FAN
Hanging on a concrete ceiling.
Before assembling the ceiling fan, remove all the parts from the packaging and
check that the following components are included in the list.
B Motor and housing assembly. 1(Unit)
C Blades 3(Units)
D Blade fixing screws. 6(Units)
E Safety washer. 6(Units)
F Omega metallic blade flanges. 3(Units)
G Fan speed control 1(Unit)
H Ceiling attachment plugs. 2(Units)
I Ceiling attachment screws. 2(Units)
J Ceiling attachment washers. 2(Units)
Instructions manual.
Guarantee card.
Of ficial service network
Follow each one of the following indications, in order to
avoid an accident that may be caused by the appliance falling and which may
lead to criminal liability for the installer
Ensure that the distance from the lowest part of the fan to the floor is at least
The appliance must be securely mounted and capable of supporting the weight
of the fan in movement
To ensure that it is hung suitably, two holes should be made in the concrete the
same diameter as the wall plug. Insert the supplied wall plug and fix the support
hook using two screws and washers supplied for the purpose.
Ensure that the ceiling is capable of supporting the minimum weight of
A.- Hook support. 1(Unit)
.-
.-
.-
.-
.-
.-
.-
.-
.-
26
