Safety
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal
injury and property damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden
columns.
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the
designated maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do
not over-tighten screws.
• Keep this instruction manual for future reference.
TV LOAD
6 - 20 kg
KG
TV SIZE
32” - 55”
DISTANCE TO WALL
73 - 565 mm
VESA COMPLIANCE
100 x 100 – 400 x 400 mm
TILT ANGLE
-5° ~ +10°
SWIVEL ANGLE
-90° ~ +90°
ROTATE ANGLE
-5° ~ +5°
Use the
Spanner
provided
Use the
Spanner
provided
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 2 17/03/2020 08:01
