TOOLING
INSTALLATION
3
A4
ø5mm
90mm
ø10mm
95mm
Ensure mounting screws are in
the centre of the timber stud.
A7
A7
A2
A3 A1
A1
A8
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting
holes, or to allow access to A/V inputs.
B8 B9
B10
B1 B2 B3 B4
B7B5 B6
A6
A5
2 people are required to lift
the unit during assembly.
