2
4
1
3
A5
TOOLING
INSTALLATION
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting holes,
or to allow access to A/V inputs.
Place the soft pad as desired to act as cushion
between the TV and the bracket.
2 people are required to lift the unit
during assembly.
A3
A2
A1
A3
A1
A4
ø4.5mm
60mm
ø10.5mm
60mm
Ensure mounting screws are in the centre
of the timber stud.
B1
B5
B2
B6
B3
B7
B4
B10
B8 B9
A5
Screw M4
Screw M8
Screw M5-M6
