2
3
4
1
2 people are required to lift the unit
during assembly.
TOOLING
INSTALLATION
A1
A3
A2
A4
A1
A3
ø4.5mm
60mm
ø10.5mm
60mm
Ensure mounting screws are in
the centre of the timber stud.
A5
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting holes,
or to allow access to A/V inputs.
Place the soft pad as desired to act as cushion
between the TV and the bracket.
B1
B7
B2
B8
B3
B9
B4
B10
B5
B11
B6
B12
B15
B13 B14
A5
Screw M4
Screw M8
Screw M5-M6
