3
TV SIZE
Swivel
TV LOAD VESA COMPLIANCE
TILT ANGLE
32” - 60”
-25° – +25°
25 kg 200 x 200 mm – 600 x 400 mm
-10° – +5°
Safety Warnings
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket.
Never exceed the designated maximum TV load.
• Assembly is required. Installation must be carried out by qualied personnel only. Incorrect assembly can result in
severe personal injury and property damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and
solid wooden columns.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the
installation. Do not over-tighten screws.
• Keep this instruction manual for future reference.
