PLJ-8LED Frequency Counter User Operating Manual 4
3. IF SETTINGS
Independent double-IF design allows the IF settings to be adjusted in minimum increments of 100 Hz.
Intermediate frequency range: 0 - 99.9999 MHz
Offset: Plus or minus IF mode can be configured
4. FREQUENCY REFERENCE
13.000MHz temperature compensated voltage controlled crystal oscillator (VC-TCXO) in 5032 package
Frequency stability: ± 2.5 ppm
5. SUPPLY
DC Input: 9V - 15V (Reverse polarity protection)
Current: 160 mA max (Test conditions: 12VDC supply, red LED display, brightness=8)
6. DISPLAY
Readout: Eight 7-segment LED digits.
Brightness: Eight LED brightness levels, factory set to maximum brightness.
7. PHYSICAL
Dimensions (L×W×H): 125.5 mm × 25.5 mm × 21.5 mm
Weight: 46 g (net weight)
8. INTERFACES
DC IN (Power Interface): HX2.54-2P socket
RF IN (signal input): HX2.54-2P socket
ICSP (programming interface): 2.54-6P Pin
