Sankosha DF-100E-V3 - Page 45

45
Rear Ｄｉａｇｒａｍ REV：3
No. Part Name Part number Q'ty Remark
201 Cylinder B1L004 1 Shoulder Expander
Joint C0B010 2
203 Knuckle Joint B6A007 1
Cylinder B1C011 1 Center Vents Clamp
Cylinder packing set B6H012 1
205 Speed Controller C1A002 10
Knuckle Joint B6B001 1
Cylinder B1A016 2 Wide Side Vents
Cylinder packing set B6H017 2
Cylinder B1C013 2 Side Vents Clamp
Cylinder packing set B6H052 2
209 Knuckle Joint B6B006 2
G0H005 1
No.～DF100EV3-0011
G0E034 1
No.DF100EV3-0012～
G0E049 1
No.DF100EV3-0062～
211 Blower Fan G2B023 1
212 Cable bear K1B039 1
213 Rubber E5V008 2
210 Motor
202
206
204
207
208
