GENERAL WARNINGS
• Read thoroughly and stick closely to the
instructions and warnings.
• Before use, ensure that the mains voltage is
the same as the voltage indicated on the
data plate of the machine.
• Connect the appliance only to 10 Amp. sock-
ets that are efficiently earthed.
• Always remove the plug from the socket
before carrying out any maintenance or
cleaning of the appliances.
• SINGLEPHASE models are supplied complete
with cable and plug for connection to the
socket.
• THREEPHASE models are provided with a
cable which must be connected to the mains
by a qualified electrician or a skilled installa-
tion technician.
• Any tampering with the machine or connec-
tions not complying with the above indica-
tions invalidate the manufacturer’s guarantee.
PARTICULAR WARNINGS
• Never tamper with the machines anyway.
• For all interventions or tampering on the
machines, always apply only to the author-
ized service centre.
• Never pull the power cable to remove the
plug from the socket.
• Only use the appliance for the purposes it is
meant for.
• Position the appliance a minimum of 5 cm
from wails so as to allow good aviation.
• Keep the appl ance away from sinks and jets
of water.
• Never leave the machine unguarded when
switched on.
• Keep it out of the reach of children and
incompetent people.
• Never switch on a machine that seems to be
faulty.
• Use only original accessories and parts.
• To avoid the danger of fire, never cover the
appliance.
• Unplug the appliance from the mains when
it is not in use.
• Let the appliance cool down before moving it
• In the interest of safety, the appliance must
always be considered as live.
• Take care, as the grinding blades may continue
rotating for a short while even after the appli-
ance is switched off.
• Do not let liquids of any kind come into contact
with the internal or external parts of the appli-
ance.
• Never put ground coffee in the hopper intend-
ed only for coffee beans.
• Do not tamper with the appliance.
• Do not touch the appliance with damp or wet
hands or feet.
• THE HOPPER MUST BE FASTENED TO THE
APPLIANCE’S GRINDING SYSTEM BY MEANS
OF THE RELEVANT SCREW which must be
inserted in the threaded hole located on the
upper grinding blade holder and in the hole
on the neck of the hopper.
• The manufacturer cannot be held responsible
for bodily injury or damage to property if these
regulations are not complied with.
If the coffee grinder is to remain inactive for
a long period, clean it carefully, dry the top
container and leave it open.
ATTENTION: Moving parts.
Macinadosatore mod. SR50-6
POSIZIONE CODICE DESCRIZIONE PZ
1
10751000 CAMPANA COMPLETA 1
2 10751002 COPERCHIO CAMPANA 1
3 10751001 CAMPANA 1
4 10751003 LINGUETTA CAMPANA 1
5 10752022 GHIERA DI REGOLAZIONE STD 1
6 10752016 PORTA MACINA FISSA D 64 1
7 10752009 COPPIA DI MACINE D 64 1
8
10752008 VITE ALBERO MOTORE TE 8X20 SX 1
9
10752006 PORTA MACINA ROTANTE D 64 1
1
0 10752011 MOLLA DI CONTRASTO PORTA MACINA 3
11A 10754017 CORPO GRIGIO 1
1
1B 10754015 CORPO ROSSO 1
11C 10754021 CORPO BIANCO 1
11D 10754022 CORPO ARANCIO 1
11E 10754023 CORPO ALL.LUC. 1
11F 10754026 CORPO CROMATO 1
12A 10754013 INTERRUTTORE DI POTENZA 0-1-AVV 1
12B 10754019 INTERRUTTORE DI POTENZA 0-1 1
13 10754018 FORCELLA 1
14 10754011 CUSCHINETTO 6202-ZZ 2
15 10754000 MOTORE F5 COMPLETO V220 1
16 10754003 CALOTTA MOTORE D 35 1
17 10754002 FONDELLO 1
18 10754008 PIEDINO 4
20 10754020 CONDENSATORE 12,5 MF (V220) 1
21 10753020 RELÈ PER 6 DOSI 2F 1
22 10754012 SPINA SHUKO V220 1
23 10753010 COPERCHIO DOSATORE 1
24 10753011 ANELLO SUPERIORE 1
25 10753009 VETRINO 1
26 10753116 TUBO ESTERNO INOX 1
27 10753128 VITE FISSAGGIO MECCANISMO 1
28 10753037 ASTINA MESCOLATORE 1
29 10753145 STELLA SUPERIORE ALLUMINIO 1
30 10753105 LAMINA 1
31 10753144 STELLA ESTERNA ALLUMINIO 1
32 10753143 STELLA INTERNA ALLUMINIO 1
33 10753032 MOLLA CONTRASTO STELLA 1
34 10753101 CORPO DOSATORE DX 1
35 10753124 MOLLA SPINTA PERNO 1
36 10753126 PIASTRINA COPRI PERNO 1
37 10753123 PERNO TRASCINAMENTO CRICCO 1
38 10753107 RONDELLA DOSATORE 1
39 10753029 CONTA-DOSI 1
40 10753148 MOLLA RICHIAMO LEVA TORSIONE 1
41 10753181 CRICCO DX OTTONE 1
42 10753047 LEVA DX ALLUMINIO 1
43 10752024 GHIERA DI REGOLAZIONE DOS. 1
44 10753077 COPERCHIO INFERIORE DX 1
45A 10753049 DOSATORE COMPLETO LEVA ALL. DX AUT.F5 1
45B 10753158 DOSATORE COMPLETO LEVA ALLUMINIO DX MAN 1
46 10753118 MICROINTERRUTTORE 1
47 10753114 COPERCHIO MICRO-INTERRUTTORE 1
48 10753119 PERNO LEVETTA 1
49 10753117 LEVA MICRO-INTERRUTTORE F5 1
50 10755000 STELLA DOSATORE ALLUMINIO COMPLETA 1
51 10753057 CORPO DOSATORE ALLUMINIO DX COMPLETO 1
52 10753113 PRESSINO D55 1
53 10755110 MICROINTERRUTTORE COMPLETO F5 1
54 10755120 LEVA GHIERA 1
55 10753127 MICROINTERRUTTORE CON LEVETTA 1
56 10753153 ASTA CONTA DOSI DX 1
57 10753046 VITE AUTOBLOCCANTE MANOPOLA DOS. 1
58 10752023 SPESSORE 0,4MM DOSATORE 1
59 10752165 TAPPINO GOMMA NERA DOS/LEVA 1
60 10753079 LAMIERINO CHIUSURA COP.INF. 1
61 10754082 INTERRUTTORE GENERALE 0-1 1
