FUNCTION CHARACTERISTICS
The standard unit has the linear characteristic between control signals and output level. It can be changed to
have the following characteristics.
Function characteristics No. Input and output characteristics
Characteristic 0 Linear characteristic
Characteristic 1 1.6th root characteristic
Characteristic 2 1.8th root characteristic
Characteristic 3 2.0th root characteristic
Characteristic 4 2.2th root characteristic
Characteristic 5 2.5th root characteristic
Characteristic 6 3.0th root characteristic
Characteristic 7 3.5th root characteristic
100.0%
100.0
90.0%
80.0%
80.0%
70.0%
60.0%
60.0%
50.0%
40.0%
40.0%
30.0%
20.0%
20.0%
10.0%
0.0%
0.0%
Output voltage
(V)
Set value
