Sanus Systems VMPL50A - Irregular TV Back with Extended Spacers

6901-002051 <05>
12
M8M6
[01]
[02]
[16]
[16]
[11]
[14]
[17]
[17]
[20]
[20]
[01]
[02]
[01]
[02]
1-4
OPT
For TVs with an irregular/obstructed back. Ensure that
the bracket is level on the back of the TV. Standard
con gurations are shown. For special applications, or
if you are uncertain about your hardware selection,
contact Customer Service.
[17]
[20]
A
[01]
[02]
A. Determine the length of the spacer
that will be required ([18], [19], or
[20]). Push the shoulder washer [17]
through the appropriate slots and
holes of the brackets [01] and [02].
Snap the required spacer onto the
shoulder washer.
