Wall Mounting
For assistance in determining wall plate location, see Height Finder at sanus.com.
2-1: Wood Stud Mounting
CAUTION: Improper use could reduce the holding power of the lag bolt. To avoid potential injuries or property damage:
 DO NOT over-tighten the lag bolts [21].
 Any material covering the wall must not exceed 16 mm (5/8 in.).
 Pilot holes MUST be drilled to a depth of 75 mm (3 in.), using a 5.5 mm (7/32 in.) diameter drill bit.
 Minimum wood stud size: common 2 x 4 in. (nominal 1.5 x 3.5 in.)
2-2: Solid concrete and Concrete Block Mounting
CAUTION: Improper use could reduce the holding power of the lag bolt. To avoid potential injuries or property damage:
 Be sure the anchors [23] seat  ush with the concrete surface.
 Mount wall plate [03] directly onto the concrete surface.
 Never drill into the mortar between blocks.
 DO NOT over-tighten the lag bolts [21].
 Pilot holes MUST be drilled to a depth of 75 mm (3 in.), using a 10 mm (3/8 in.) diameter drill bit.
 Minimum solid concrete thickness: 8 in.
 Minimum concrete block size: 8 x 8 x 16 in.
