Sanus Systems VMPL50A - Hang TV onto Wall Plate

6901-002051 <05>
17
3
OPT
1
2
10° 8.5°
3
[03]
[02]
[24]
Hang the TV with Mounting Brackets onto the Wall Plate
CAUTION: You will need assistance with this step.
Install the
TV / Bracket
assembly by
 tting the top
hooks of the
mounting
brackets over
the top edge of
the wall mount.
Swing the
mounting
brackets down
until the spring
loaded locking
tabs slip over
and fully engage
the bottom
edge of the wall
mount. You will
hear an audible
“CLICK”.
Tilt tension can be
adjusted with the
vertical bracket
knobs by hand or
using the hex key
[24].
