SANY SCC3000US - Fixed Jib Operating Condition (FJ)

SCC3000US Crawler Crane―Operation Manual
Section 4-Load Charts
- 6/16 -
3.2 Fixed Jib Operating Condition(FJ)
76.5m 250'12" boom
+31m 101'8" jib
76.5m 250'12" boom
+25m 82'0'' jib
76.5m 250'12'' boom
+19m 62'4" jib
76.5m 250'12" boom
+13m 42'8" jib
28.5m 93'6" boom
+31m 101'8'' jib
28.5m 93'6" boom
+25m 82'0" jib
28.5m 93'6" boom
+19m 62'4" jib
28.5m 93'6" boom
+13m 42'8" jib
F ixed Jib(Jib Angle: 10° and 30° )
11 5 377'4"
11 0 360'1
105 344'6"
100 328'1"
95 311'8"
90 295'3"
85 278'10"
80 262'6"
75 246'1"
70 229'8"
65 213'3"
60 196'10"
55 180'5"
50 164'0"
45 147'8"
40 131'3"
35 114'10"
30 98'5"
25 82'0"
20 65'7"
15 49'3"
10 32'10"
5 16'5"
0 0'0"
16'5" 49'3" 82'0"
114'10"
147'8"
180'5" 213'3"
246'1" 278'10" 311'8"
32'10"
65'7'' 98'5"
131'3"
164'0"
196'10'' 229'8" 252'6"
295'3"
328'1"
Hight Above Ground(m) (ft in)
Operating Range (m) (ft in)
