SANY SCC3000US - Luffing Jib Operating Condition (LJ)

- 7 / 16 -
SCC3000US Crawler Crane ― Operation Manual
Section 4-Load Charts
3.3 Lufng Jib Operating Condition(LJ)
170'7"
52m
141'1"
43m
121'4"
37m
101'8"
31m
201'9"
61.5m
123'
37.5m
52m 170'7"
43m 141'1"
37m 121'4"
31m
101'8"
25m 82'0"
22m 72'2"
61m
200'1"
Main boom angle: 88°
75°
5m 16’4”
75°
120 393'8"
11 5 377'4"
11 0 360'1
105 344'6"
100 328'1"
95 311'8"
90 295'3"
85 278'10"
80 262'6"
75 246'1"
70 229'8"
65 213'3"
60 196'10"
55 180'5"
50 164'0"
45 147'8"
40 131'3"
35 114'10"
30 98'5"
25 82'0"
20 65'7"
15 49'3"
10 32'10"
5 16'5"
0 0'0"
16'5" 49'3" 82'0" 114'10"
147'8''
180'5"
213'3" 246'1"
278'10"
32'10"
65'7"
98'5"
131'3" 164'0" 196'10"
229'8"
252'6"
295'3"
